Reliable Cellular Networks in Rural Areas

GL-X3000 is a Wi-Fi 6 cellular gateway designed to provide reliable cellular networks in remote locations and high speed internet in urban areas. It has six external antennas for long range connection, two SIM Cards for selecting between the ISP with stronger connections, and Multi-WAN between the WAN port, SIM Card, and Repeater.

Supports 5G NR & Multi-WAN
Dual-SIM, Single Modem
Wi-Fi 6 Max. 574 Mbps (2.4GHz) + 2402 Mbps (5GHz) Wi-Fi Speeds
OpenVPN speed up to 150 Mbps; WireGuard speed up to 300 Mbps

Learn More

Spitz AX (GL-X3000NR) 5G NR Frequency Bands

Module: RM520N-GL
5G NR	NSA	n1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/ 48/ 66/ 70/ 71/ 75/ 76/ 77/ 78/ 79
5G NR	SA	n1/ 2/ 3/ 5/ 7/ 8/ 12/ 13/ 14/ 18/ 20/ 25/ 26/ 28/ 29/ 30/ 38/ 40/ 41/ 48/ 66/ 70/ 71/ 75/ 76/ 77/ 78/ 79
LTE	LTE-FDD	B1/ 2/ 3/ 4/ 5/ 7/ 8/ 12/ 13/ 14/ 17/ 18/ 19/ 20/ 25/ 26/ 28/ 29/ 30/ 32/ 66/ 71
	LTE-TDD	B34/ 38/ 39/ 40/ 41/ 42/ 43/ 48
	LAA	B46
UMTS	WCDMA	B1/ 2/ 4/ 5/ 8/ 19
GNSS		GPS/ GLONASS/ BDS/ Galileo/ QZSS

Spitz AX (GL-X3000C16) 4G LTE Frequency Bands

Module: EM160R-GL
LTE	LTE-FDD	B1/B2/B3/B4/B5/B7/B8/B12/B13/B14/B17/B18/B19/B20/B25/B26/B28/B29①/B30/B32①/B66
	LTE-TDD	Intra-band and Inter-band
	DL 2CA	Intra-band and Inter-band
	DL 3CA	Intra-band and Inter-band
	DL 4CA	Intra-band and Inter-band
	DL 5CA	Intra-band and Inter-band within 5 bands
	DL 4×4 MIMO	B1/B2/B3/B4/B7/B25/B30/B32①/B38/B39/B40/B41/B66
	DL 256QAM	Supported
	UL 2CA	Intra-band
	UL 64QAM	Supported
UMTS	WCDMA	B1/B2/B3/B4/B5/B6/B8/B19
GNSS		GPS/GLONASS/BeiDou(COMPASS)/Galileo

Notes: ①: For secondary component carrier only.

Recreational Vehicles(RV) Deployment

Spitz AX is your reliable router on the road, working in an RV. Spitz AX allows you to access multiple WAN connectivity, switching easily between the WAN port, SIM cards, and Repeater. It has 6 external antennas to increase connectivity. When an amplifier is needed for extra stability of your internet services in remote locations, Spitz AX can connect to an extended GPS antenna or wired dome antenna of your choice. To secure your secured network gateway on a bumpy ride, you can easily deploy Spitz AX to your RV's interior walls.

Dual SIM for selecting the ISP with stronger connections

Fast Wi-Fi 6 connection for all the devices in the RVs

Secure network when connecting to a public Wi-Fi

Reliable and Uninterrupted RV Internet

Spitz AX (GL-X3000) is equipped with advanced features, including Multi-WAN, Load-balancing, and Failover, to ensure RV users experience quality internet connections when traveling in both rural and urban areas.

Multi-WAN

Enhanced Bandwidth and Network Stability

Spitz AX's Multi-WAN technology lets RV users utilize multiple connection methods, including Ethernet, Repeater, Cellular, and Tethering, at the same time, increasing the total bandwidth and staying connected when a single connection type is down.

Load-balancing

Optimal Bandwidth Usage

Spitz AX's Load-balancing capabilities let users distribute bandwidth by custom proportion among multiple connection methods, prioritizing data consumption among preferred connection types, and minimizing network congestion.

Failover

Uninterrupted Connection

Spitz AX supports Network Failover and the option to configure Failover priorities among multiple connection methods. If the primary connection fails, the router will automatically switch to the next connection method without interruption.

_{30+ VPN SERVICE PROVIDERS FOR YOUR SELECTION}

Securing Your Internet In The Background

Spitz AX is pre-installed with OpenVPN and WireGuard® supporting 30+ VPN services. It automatically encrypts all network traffic within the connected network, including guest or client devices that are not capable of running VPN. Spitz AX can also host VPN servers and supports VPN Cascading, automatically forwarding data from its VPN server to the VPN client within the same device.

WireGuard® is a registered trademark of Jason A.Donenfeld.

WireGuard

Max. 300Mbps

OpenVPN

Max. 150Mbps

* Tests conducted on a local network. Real world speeds may differ depending on your network configuration.
* OpenVPN and WireGuard speeds will be slower when running the device as a server. Results above are in client mode.

Access Your Local Network Storage from Anywhere

Our local network storage feature supports SMB Protocol and WebDAV protocol. By plugging an external USB hard disc into the router, you can create a private network to store and share your documents. No matter for work or family, you can benefit from easy file access. Save space on your devices by storing photos and videos on the network.

Runs on OpenWrt 21.02 (Kernel version 5.4)

Spitz AX runs on GL.iNet's latest SDK4.0+ firmware and presents a user-friendly interface for common users to set up the router with minimal inputs, and an extended customization experience for advanced users to install plug-ins and applications. Spitz AX runs on GL.iNet's proprietary firmware based on OpenWrt (v21.02 Kernel version 5.4), supporting more than 5,000 ready-made plug-ins for customization. Simply browse, install, and manage packages with our no-code interface within the Admin Panel.

Everyday Scenario for Spitz AX

Remote Work

VPN cascading for you to access your company’s local server remotely

Rural Areas

Stable and long-range network connection using multi-WAN & antennas in your sizeable country house

Road Trips

Dual SIM cards to switch data services for your group in a snap

Co-working space

Secure your confidential data and network speed while using public Wi-Fi Services

Block Ads & Tracking for Free

AdGuard Home Ready on Router

Block ads for all client devices

Block online trackers and analytics by default

Block age-restricted content and services as needed

Customizable DNS filters

Keep sensitive online data safe

Enforce family browsing security

_{PREVENT MAN-IN-THE-MIDDLE ATTACKS}

DNS over TLS & DNS over HTTPS

Spitz AX supports both DNS over TLS and DNS over HTTPS to enhance network privacy and security, providing users with the flexibility to choose between encryption depending on the network type. DNS over TLS uses encryption to secure DNS communications, while DNS over HTTPS uses the HTTPS protocol for an additional layer of security.

Remote Access and Management

Spitz AX comes with GL.iNet's GoodCloud remote device & networks management platform, providing users with data usage monitoring and technical support services with remote access to the device admin panel for maintenance and troubleshooting. It also enables batch device management, firmware updates, analytics and notifications for status updates, enabling users to manage devices efficiently.

DFS Certification in US, CA, EU and UK

Spitz AX is approved to use DFS (Dynamic Frequency Selection), letting the router's 5GHz network use additional frequencies normally reserved by military, satellite, and weather radar applications. The selection of additional channels can lower network congestion under high density network environments.

Empowering IoT Connectivity with Customizable BLE, Thread, and Zigbee Integration

The Spitz AX offers IoT customization options including BLE, Thread, and Zigbee protocols. While customization is a key aspect of the Spitz AX, it is important to note that this feature is exclusively available for bulk orders.

Carrier Certified IoT Device

Spitz AX is certified by T-Mobile and AT&T under the IoT device category, and is therefore compatible with these network providers. Spitz AX’s IoT application is supported and interoperable with these network infrastructures, ensuring seamless connectivity and reducing the risk of connectivity issues.

Compatible with GL.iNet eSIM Solution

Experience seamless connectivity with the Spitz AX, fully compatible with GL.iNet’s advanced eSIM solution, which supports both physical eSIM cards and integrated eSIM chips. eSIMs can be programmed remotely, offering unmatched convenience, flexibility, space-saving, and enhanced security. For consumers, this means effortlessly switching networks and avoiding roaming charges, while businesses benefit from centralized management, multi-device support, and secure data management.

Learn More

Model Comparison

Spitz / GL-X750V2 4G LTE Smart Router	VS	Spitz AX / GL-X3000 Wi-Fi 6 4G/5G Router
QCA9531, @650MHz	CPU	MediaTek Dual-core, @1.3GHz
DDR2 128MB / NOR Flash 16MB	Memory / Storage	DDR4 512 MB / EMMC 8GB
IEEE 802.11a/b/g/n/ac	Protocol	IEEE 802.11a/b/g/n/ac/ax
300Mbps (2.4GHz), 433Mbps (5GHz)	Wi-Fi Speed	574Mbps (2.4GHz), 2402Mbps (5GHz)
10/100Mbps	Ethernet Speed	WAN Port: 10/100/1000/2500Mbps LAN Port: 10/100/1000Mbps
1 x WAN, 1 x LAN	Ethernet Ports	1 x 2.5Gbps WAN, 1 x LAN
Max.512GB	TF Card Slot	Max.1TB
1 x Micro SIM card slot	SIM Card Slot	2 x Nano SIM card slot
Max.10Mbps	OpenVPN (Via Ethernet)	Max.150Mbps
Max. 38Mbps	WireGuard® (Via Ethernet)	Max. 300Mbps

* Tests conducted on a Local Network. Real world speeds may differ depending on your network configuration.
* OpenVPN and WireGuard speeds will be slower when running the device as a server. Results above are in client mode.

Product Reviews from Youtubers

Spitz AX (GL-X3000) Reviews

Ultimate RV Internet Setup: Triple WAN Router Changes Everything
Why You Need a New Internet Gateway
Take your WiFi with you! GL.iNet Beryl AX & Spitz AX
THE ULTIMATE MOBILE INTERNET SETUP?
Our 5G Campervan WiFi Setup - With the GL.iNet Spitz AX Router (GL-X3000)
Don’t buy 5G Netgear M6 or RUTX50 without watching this first! Spitz AX GL-X3000 5G Router Review
AX Spitz 5G Router Review
Gl.INet GL-X3000NR overview
Notre solution INTERNET et WIFI dans notre camping-car !!! GL-X3000 SPITZ AX
MOBILE INTERNET Woes - New 5G Upgrade: Has it fixed it?

What Our Beta Testers are Saying

I truly think that this device is absolutely amazing, I was able to have a good 5G connection inside my home where my iPhone is barely able to connect to the network.

Piero Cafa

This device is what I have been waiting for! I did change the IMEI number to that of my iPad so the device would appear as an iPad on the T-Mobile account page. I am running the T-Mobile Business Data Line for $10/month which already includes taxes and fees. I didn't have to adjust any other settings just popped in the SIM Card, click auto setup inside the router interface and it started working! The speeds are more than what i am getting with my T-Mobile Home Internet $30/month plan.

Richard Mendoza

*5G NR
Module

^#IoT

OpenWrt
Pre-installed

Wi-Fi 6

VPN Client /
Server

AdGuard

MU-MIMO

DFS

* The Spitz AX is available in two versions: 4G LTE (CAT16) and 5G NR (CAT19).
^# Customization options are also available for bulk orders.

The cellular feature in Spitz AX (GL-X3000) is restricted in Russia, Belarus, Cuba, Iran, North Korea, Syria, and the Crimean Peninsula due to modem limitations.
